Belt and Chain Drives Crossword Puzzle

Download and print this Belt and Chain Drives crossword puzzle.

PDF will include puzzle sheet and the answer key.

OFFSET LINK : A device for extending a chain so that it has an odd number of links.
CONE PULLEY : A tapered wheel used in pairs with a flat belt to create a variable speed drive called a constant variable transmission (CVT).
PITCH : The distance between the center of one element of a drive system and the next, or the number of such drive elements per unit of distance (usually 1 inch).
PULLEY : A drive wheel with an outer flat surface designed for a flat belt to ride on.
PITCH DIAMETER : The diameter of the pitch circle.
CONNECTING LINK : A device used to connect the ends of a chain into a continuous loop.
CROWNED PULLEY : A wheel with a convex shape that helps keep flat belts centered.
TENSIONER : A device that applies a force to a belt or chain to keep it tight.
OVER CORD : A component of V-belt construction responsible for keeping the belt strait on the long straight stretches between sheaves.
TRACKING : The Process of adjusting a flat belt drive’s tension to keep it even on both sides so that it rides in the center of the drive.
SHEAVE : A drive wheel with a V shaped or round groove in its outer surface designed for a V-belt or round belt to ride in.
PITCH CIRCLE : The imaginary circle around a drive component wheel where the actual power transmission medium goes around the wheel.
UNDER CORD : A component of V-belt Construction responsible for applying pressure to the grove walls as the belt bends around the sheave.
IDLER : A wheel in a drive system that is not attached to the driver or driven machines but is necessary to keep components of the drive system in the place where they belong.
WHEEL : Any round device mounted on a shaft and designed to transmit power to another wheel or to another drive system component.
CHAIN : A Flexible loop composed of individual links that uses positive drive to transmit power between 2 or more wheels called sprockets.
LACING : A way of connecting to ends of a flat belt together.
TENSION : A force that tends to stretch something, or the process of applying such a force.
SPROCKET : A drive wheel designed to mesh with a chain.
BELT : A flexible loop that, most often, uses friction drive to transmit power between 2 or more pulleys, sheaves, or other wheels.
PIN LINK : A component of a roller chain that has link plates and pins.
